Gravity-beating ultrasonic tweezers provide a sound route to bio-engineering

Sound engineering: complex sonotweezers can manipulate and arrange many small particles simultaneouslyProfessor Bruce Drinkwater, University of Bristol

Press release issued: 30 May 2014

Pioneering ‘tweezers’ that use ultrasound beams to grip and manipulate tiny clusters of cells under electronic, push-button control could lead to life-changing medical advances, such as better cartilage implants that reduce the need for knee replacement operations.

Using the crafted sound fields, cartilage cells taken from a patient’s knee can be levitated for weeks in a nutrient-rich fluid. This means the nutrients can reach every part of the culture’s surface and, combined with the stimulation provided by the ultrasound, enables the cells to grow and to form better implant tissue than when cultured on a glass petri dish.

By holding the cells in the required position firmly but gently, the tweezers can also mould the growing tissue into exactly the right form so that the implant is truly fit-for-purpose when inserted into the patient’s knee. Over 75,000 knee replacements are carried out each year in the UK; many could be avoided if cartilage implants could be improved.

This is just one potential application of ultrasonic tweezers* developed with Engineering and Physical Sciences Research Council (EPSRC) funding by a closely integrated team harnessing and combining expertise at four UK universities. The team comprises researchers from the Universities of Bristol, Dundee, Glasgow and Southampton, as well as a range of industrial partners; their extremely close and highly productive collaboration, supported by the four-year EPSRC grant, has established the UK as a world leader in this fast-growing technology.

Bruce Drinkwater, Professor of Ultrasonics from the University of Bristol’s Department of Mechanical Engineering, who co-ordinated the programme, said: “Ultrasonic tweezers have all kinds of possible uses in bioscience, nanotechnology and more widely across industry. They offer big advantages over optical tweezers that rely on light waves and also over electromagnetic methods of cell manipulation; for example, they have a complete absence of moving parts and can manipulate not just one or two cells (or other objects) at a time but clusters of several centimetres across – a scale that makes them very suitable for applications like tissue engineering.”

The tweezers developed with EPSRC funding involve multiple, tiny beams of ultrasonic waves that, in a typical device, point into a 10 mm-diameter chamber from all around. With the aid of a powerful microscope to monitor the procedure, the forces generated by the waves can then be manipulated so that they nudge cells into the required position, turn them around, or hold them firmly in place.

Professor Martyn Hill from the University of Southampton, who led the cartilage tissue engineering work in collaboration with Dr Rahul Tare and Professor Richard Oreffo, explained: “Ultrasonic tweezers can provide what is, in effect, a zero-gravity environment perfect for optimising cell growth. As well as levitating cells, the tweezers can make sure that the cell agglomerates maintain a flat shape ideal for nutrient absorption. They can even gently massage the agglomerates in a way that encourages cartilage tissue formation.”

The research programme has also shown that ultrasonic tweezers can be used to build up cell tissue layer by layer and, as an example, the team has produced a microscopic tartan tissue. They anticipate that the tweezers could, for instance, help to reconstruct nerve tissue after severe trauma such as limb amputation. Professor David Cumming from the University of Glasgow said: “It could ultimately be possible to develop a wearable device that produces a kind of acoustic scaffold to help guide a patient’s nerve cells as they regenerate.”

The team has made a range of innovative tweezing devices, such as a real-life Sonic Screwdriver and a microscopic acoustic Tractor Beam that have turned the science fiction fantasies of Dr Who and Star Trek into reality. Professor Sandy Cochran of the University of Dundee said" “Our partnership with industry has been vital to developing devices and capabilities that are delivering unprecedented sophistication in the field of ultrasound.”

His colleague Dr Mike MacDonald added: “This has enabled us to undertake cutting-edge physics experiments that could lead to big advances in the application of ultrasound-based techniques in sectors such as healthcare. Looking at the programme overall, close collaboration across the multi-university team has been critical to its success, with the interaction between researchers making a particularly significant contribution.”

Together, the team has built a platform of understanding that will enable ultrasonic tweezer technology to be refined and miniaturised and specific uses to be explored and developed in the next few years. The first real-world applications, in sectors such as bioscience and electronics, could potentially come on-stream within around 5 years.

Further information

* The use of ultrasound to manipulate biomolecules, cells and other microscopic particles safely and effectively is well-proven, with researchers around the world now working to exploit this basic phenomenon in the most efficient and productive way. These EPSRC-funded projects have delivered a step change in such capabilities by developing ultrasonic tweezers that harness electronically controlled ultrasonic transducer systems to produce a ‘landscape’ of forces and modify it as required. In many ways, this work builds on the development of optical tweezers in the 1980s and 1990s; using laser beams to hold and move microscopic particles, optical tweezers are now a well-established research technology. (For more information on this basic concept and its capabilities, see http://www.bristol.ac.uk/physics/research/nanophysics/facilities/tweezers)

Total EPSRC support for the ‘Electronic Sonotweezers: Particle Manipulation with Ultrasonic Arrays’ programme has amounted to just over £3.6 million. The four-year programme commenced in 2009.

The industrial partners involved in the programme include: Agilent, Crystapol International, the Defence Science and Technology Laboratory (DSTL), Leica Genetix Ltd, Loadpoint Ltd, Piezo Composite Transducers (PCT) Ltd, Weidlinger Associates Inc, and IKTS-Fraunhofer.

Sources of information on the number of knee replacements in the UK:

http://www.nhs.uk/Conditions/Knee-replacement/Pages/Kneereplacementexplained.aspx

www.audit-scotland.gov.uk/docs/health/2010/nr_100325_orthopaedic_services.rtf
